| Item | Humidity Sensor |
| Connection Type | Screw Terminal , Screw Terminals |
| Display Type | Digital |
| Electrical Connection Type | Screw Terminals |
| Features | Controller Configuration Switch, Manual Override Pushbutton, Power Supply Selection Switch, User-Selectable Humidity Output, Warmer/Cooler Setpoint Dial |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Housing Color | White |
| Housing Material | Plastic |
| Measurement Type | Single |
| Overall Height | 3 1/4" |
| Overall Length | 1 1/2" |
| Overall Width | 3 1/4" |
| Probe Length | 6" |
| Relative Humidity Range | 0% to 100% |
| Rh Sensor | Thermal |
| Sensing Element Type | Nickel |
| Temp. Accuracy | -0.34°F to +0.34°F |
| Type | Cooler Adjustment, Wall Mount, Warmer , Wall Mount, Warmer/Cooler Adjustment |
| Application | HVAC |
| For Use With | BAS/DDC System |
| Humidity Output | 0-10/0-5V DC |
| Loop Resistance | 1000 ohms |
| Maximum Operating Temperature | 131°F |
| Maximum Sensing Temperature | 131°F |
| Minimum Operating Temperature | 32°F |
| Minimum Sensing Temperature | 32°F |
| Mounting Location | Wall Mount |
| Power Required | 18 to 25 mA at 20 to 30V AC, 4.5 to 7.5 mA at 14 to 30V DC |
| Product Type | Room Temperature and Humidity Sensor |
| Relative Humidity Accuracy | +/-3% of Full Scale |
| Series | HE-6800 Series |
| Standards | E107041, CCN PAZX, UL 916, UL LISTED |
| Temperature Accuracy | +/-0.34°F |
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 8.1 |
| Ship length (cm) | 3.66 |
| Ship width (cm) | 8.1 |
| HS code | 9025198080 |
| Country of Origin | MX |
| Product | Model | Type | Price | |
|---|---|---|---|---|
 |
HE-68N2-1N00WS | Wall Mount, Warmer/Cooler Adjustment | €640.29 | |
 |
HE-68N3-0N00WS | Wall Mount | €596.39 |
