| Item | Control |
| Application | Heat Or Cool |
| Contact Rating Resistive @ 120v | 10A |
| Contact Rating Resistive @ 240v | 8A |
| Contact Rating Resistive @ 277v | 7.2A |
| Depth | 14 5/8" |
| Enclosure Color | Gray |
| Enclosure Finish | Galvanized |
| Enclosure Material | Steel |
| Enclosure Nema Rating | NEMA 1 |
| Full Load Amps @ 120v Ac | 6A |
| Full Load Amps @ 240v Ac | 3A |
| Height | 4 3/8" |
| Locked Rotor Amps @ 120v | 36A |
| Locked Rotor Amps @ 240v | 18A |
| Max. Control Temp. | 110°F |
| Max. Operating Temp. | 240°F |
| Min. Control Temp. | 30°F |
| Min. Operating Temp. | -30°F |
| Operating Temp. Range | -30°F to +240°F |
| Overall Depth | 14 5/8" |
| Overall Height | 4 3/8" |
| Overall Width | 2 1/8" |
| Pilot Duty | 125VA @ 24 To 600V AC |
| Sensor Type | Hydraulic Air Coil |
| Switch Action | Open On Rise/Close On Rise |
| Switch Type | SPDT |
| Temperature Scale | Celsius, Fahrenheit |
| Voltage | 24-277V AC , 24-600V AC |
| Width | 2 1/8" |
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 11.11 |
| Ship length (cm) | 37.15 |
| Ship width (cm) | 5.4 |
| Country of Origin | MX |
