| Item | Control |
| Application | Heat Or Cool |
| Bulb Dia. | 1/4" |
| Bulb Length | 9 1/2" |
| Capillary Length | 72" |
| Changeover Type | Manual |
| Compatible System Type | Hot Water Heating Controls |
| Contact Rating Resistive @ 120v | 22A |
| Contact Rating Resistive @ 240v | 22A |
| Contact Rating Resistive @ 277v | 22A |
| Contact Type | Snap Action |
| Control Type | Knob |
| Depth | 1 7/8" |
| Differential Type | Fixed |
| Enclosure Material | Steel |
| Enclosure Nema Rating | NEMA 1 |
| Full Load Amps @ 120v Ac | 16A |
| Full Load Amps @ 240v Ac | 8A |
| Locked Rotor Amps @ 120v | 96A |
| Locked Rotor Amps @ 240v | 48A |
| Max. Control Temp. | 300°F |
| Max. Operating Temp. | 350°F |
| Min. Control Temp. | 100°F |
| Min. Operating Temp. | -35°F |
| Mounting Type | Surface Mount |
| Number Of Cooling Stages | 1 |
| Number Of Heating Stages | 1 |
| Number Of Poles | 1 |
| Pilot Duty | 125 VA @ 24 To 600V AC |
| Resistive Amps @ 208v Ac | 22A |
| Sensor Location | Remote |
| Sensor Type | Hydraulic Capillary Bulb |
| Switch Action | Open On Rise |
| Switch Type | SPST |
| Thermostat Type | High Range Indoor Single Stage Controls |
| Voltage | 120-240V AC , 24-600V AC |
| Bulb Diameter | 1/4" |
| Contact Rating | 120/208/240V AC |
| Electrical Connection Type | Hardwired, Screw Terminal |
| Maximum Control Temperature | 300°F |
| Maximum Operating Temperature | 350°F |
| Minimum Control Temperature | 100°F |
| Minimum Operating Temperature | -35°F |
| Overall Depth | 1 7/8" |
| Pilot Duty Rating | 125 VA @ 24 to 600V AC |
| Temperature Differential | 7°F |
| Temperature Scale | Fahrenheit/Celsius |
