| Item | Electronic Flowmeter |
| Compatible Flow Material | Water |
| Connection Size | 36" |
| Connection Type | Insertion |
| Display Type | Digital , LCD |
| Display Units | Programmable |
| Fitting Type | Insertion |
| Flow Range | 352-63452 GPM |
| Flow Rate - Maximum | 20 GPM |
| Flow Rate - Minimum | 1 GPM |
| Flow Rate Range | 352-63452 GPM |
| Flowmeter Type | Paddlewheel |
| Fluid Temp. | -4°F to +150°F |
| For Pipe Size | 12" to 36" |
| Frequency - Maximum | 800 Hz |
| Frequency - Minimum | Not Applicable |
| Housing Material | Stainless Steel |
| Includes Flow Rate Adjustment Knob | No |
| Includes Pressure Gauge | No |
| Max. Operating Pressure | 1000 psi |
| Mounting Orientation | Horizontal |
| O-ring Material | Viton |
| Pulse Rate | Not Applicable |
| Rotor Material | Stainless Steel |
| Sensor Type | Paddle Wheel |
| Shaft Material | Tungsten Carbide |
| Type | Impeller |
| Unit Of Measure | Gallons |
| Viscosity - Maximum | 32.6 SUS |
| Wetted Material | Stainless Steel, Brass, Peek, PPS |
| Wetted Material Grade | Grade 316 |
| Accuracy | +/-1% |
| Flow Rate | 1-20 GPM |
| Fluid Connection | 36" Insertion |
| Includes Totalizer | Yes |
| Max. Flow Rate | 20 GPM |
| Max. Frequency | 800 Hz |
| Max. Media Temperature | 150°F |
| Max. Viscosity | 32.6 SUS |
| Max. Voltage | 35V DC |
| Media Temp. Range | -4°F to 150°F |
| Min. Flow Rate | 1 GPM |
| Min. Media Temperature | -4°F |
| Mounting Location | Insertion |
| Output Type | 4-20 mA |
| Product Type | Flow Sensor |
| Seal Material | Viton |
| Ship weight (kg) | 3.51 |
