| Item | Electronic Flowmeter |
| Compatible Flow Material | Conductive Liquids, Water, Water-Like Liquids |
| Connection Size | 1" |
| Connection Type | BSPP |
| Display Type | LED |
| Display Units | Gallons, GPH, GPM, Temp. |
| Flow Material | Conductive Media |
| Flow Range | 0.1-26.4 GPM |
| Flow Rate - Maximum | 26.4 GPM |
| Flow Rate - Minimum | 0.1 GPM |
| Flow Rate Range | 0.1-26.4 GPM |
| Flowmeter Type | Electromagnetic |
| Fluid Temp. | -4°F to +176°F |
| For Pipe Size | 1" |
| Frequency - Maximum | Not Applicable |
| Frequency - Minimum | Not Applicable |
| Housing Material | Stainless Steel |
| Housing Material Grade | Grade 316L |
| Includes Flow Rate Adjustment Knob | No |
| Includes Pressure Gauge | No |
| Length | 4" |
| Max. Operating Pressure | 232 psi |
| Max. Pressure | 232 psi |
| Mounting Orientation | Universal |
| O-ring Material | Viton |
| Output Type | Programmable |
| Overall Length | 4" |
| Sensor Type | Magnetic |
| Shaft Material | Stainless Steel |
| Unit Of Measure | Gallons |
| Viscosity - Maximum | 70 SUS |
| Wetted Material | Stainless Steel, PPS, Peek |
| Wetted Material Grade | Grade 316L |
| Ship weight (kg) | 0.59 |
