| Item | Transmitter |
| Body Material | Stainless Steel, PA, EPDM |
| Circuit Type (cylindrical Photoelectric Sensor) | NPN/PNP |
| Diameter | 18 mm |
| Diameter (cylindrical Photoelectric Sensor) | 18 mm |
| Diameter - Cylindrical Photoelectric Sensor | 18 mm |
| Features | Pmma Lens, Reverse Polarity Protection |
| Grade | Grade 316L |
| Housing | Threaded Type |
| Ip Rating | IP67 |
| Length | 72 mm |
| Length (cylindrical Photoelectric Sensor) | 72 mm |
| Length - Cylindrical Photoelectric Sensor | 72 mm |
| Light Source | Red LED |
| Light Spot Dimensions Refer To | At Maximum Range |
| Min. Object Size | 1000 mm |
| Nema Rating | Non-NEMA , Not Rated |
| Number Of Pins | 4 |
| Number Of Sensor Pins | 4 |
| Operating Frequency | 1000 Hz |
| Operating Mode (photoelectric Sensor) | Selectable Light On, Dark On |
| Operating Temp. | -25°C to +80°C |
| Operation Mode | Selectable Light On/Dark On |
| Power Requirement (cylindrical Photoelectric Sensor) | 10-36V DC |
| Range Adjustable | No |
| Reverse Polarity Protection | Yes |
| Sensing Method | Through Beam Transmitter |
| Sensing Method (cylindrical Photoelectric Sensor) | Through Beam Transmitter |
| Sensing Method - Cylindrical Photoelectric Sensor | Through Beam Transmitter |
| Sensor Connection Type | Male |
| Sensor Size | M12 |
| Shape | Cylindrical |
| Transmitter / Receiver | Transmitter |
| Type Of Light | Red Light |
| Dc Supply Voltage Rating | 10-36V DC |
| Display Qty | 1 |
| Electrical Connection | M12 |
| Electrical Installation Type | Direct Connector |
| Emitted Sensor Light | Red Light |
| Includes Indicator Lights | Indicator Lights Included |
| Load Current - Maximum | 20 mA |
| Minimum Object Size | 1000 mm Dia. Light Spot |
| Nema Enclosure Rating | No Enclosure |
| Nominal Sensor Diameter | M18 Threaded |
| Operating Temperature - Maximum | 176°F |
| Operating Temperature - Minimum | -13°F |
| Output Circuit | N/A for Transmitters |
| Overall Diameter | 18 mm |
| Overall Height | 72 mm |
| Sensing Distance - Maximum | 25m |
| Sensing Distance - Minimum | 0 m |
| Sensor Body Style | Cylindrical |
| Sensor Diameter | 18 mm |
| Sensor Face Orientation | Right Angle |
| Sensor Switching Mode | Selectable Light On/Dark On |
| Standards | CE, CULUS, UKCA |
| Supply Voltage | 10-36V DC |
| Supply Voltage Type | DC-Only |
| Switching Frequency | 1 kHz |
| Through Beam Sensor Component | Photoelectric Sensor Transmitter |
| Ship weight (kg) | 0.06 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
