| Item | Switch |
| Action | SPDT |
| Amps | 20A |
| Color | White |
| Dielectric Strength | 1500V AC |
| Grade | Commercial |
| Height | 1.54" |
| Hp | 1 hp to 2 hp |
| Indicator | Blue LED |
| Length | 4 7/25" |
| Material | Thermoplastic |
| Number Of Poles | 1 |
| Operating Temp. | -40°C to +75°C |
| Style | Style Line |
| Switch Function | Maintained |
| Switch Type | 3-Way |
| Voltage | 120-227V AC |
| Voltage (ac) | 120-277V AC |
| Width | 1 11/25" |
| Wiring Method | Wiring Module |
| Current Rating | 20A |
| Grounding | Grounded |
| Horsepower Rating | 2 hp |
| Illuminated | Yes |
| Market | Commercial Grade |
| Number Of Switches | 1 |
| Overall Height | 1 1/2" |
| Overall Width | 1 2/5" |
| Resistance Properties | Impact Resistant |
| Standards | UL LISTED |
| Switch Style | Rocker |
| Voltage Rating | 120/277V AC |
| Wire Connection Location | Back |
| Wire Connection Type | Modular Wiring |
| Wire Connection Types | Snap In Module |
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 3.91 |
| Ship length (cm) | 10.87 |
| Ship width (cm) | 3.66 |
| HS code | 8536507000 |
| Country of Origin | US |
| Product | Model | Action | Application Environment | Color | Connectivity | Grade | Height | Length | Locking | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL1284I | DPDT | Commercial Environments | Ivory | Side Wired Only | Specification | 1.45" | 3.28" | No | €155.12 | |
 |
HBL1386L | DPDT | Industrial Environments | Black | Back and Side Wired | Locking | 1.19" | 4.06" | Yes | €169.26 | |
 |
HBL1557L | SPDT | Industrial Environments | Black | Back and Side Wired | Heavy Duty Industrial | 1.89" | 4.06" | Yes | €65.28 | |
 |
SNAP2123ILBKNA | SPDT | - | Black | - | Commercial | 1.54" | 4.28" | - | €81.15 | |
 |
SNAP2123ILINA | SPDT | - | Ivory | - | Commercial | 1.54" | 4.28" | - | €81.15 | |
 |
SNAP2123ILRNA | SPDT | - | Red | - | Commercial | 1.54" | 4.28" | - | €81.15 | |
 |
SNAP2123INA | SPDT | - | Ivory | - | Commercial | 1.54" | 4.28" | - | €64.43 |
