HUBBELL WIRING DEVICE-KELLEMS SHC1036CR Liquid Tight Connector 3/4 inch Brown
Get it by Tuesday, Jun 17
€19.48 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Liquid Tight Connector |
| Color | Brown |
| Conduit Size | 3/4" |
| Connector Type | Straight |
| Length | 2.156" |
| Material | Nylon |
| Body Color | Gray |
| Body Material | Nylon |
| Box Connection | 3/4" MNPT |
| Bushing Material | Neoprene |
| Collar Material | Nylon |
| Compatible Conduit Trade Size | 3/4" |
| Compatible Conduit Type | Liquid Tight Cord Connector |
| Connection Orientation | Straight |
| Cord Dia. Range | 0.50" to 0.63" |
| Environmental Rating | Hazardous Locations, Not Flammable |
| For Maximum Cable Od | 0.63" |
| For Minimum Cable Od | 0.5" |
| For Use With | Kellems Wire Management |
| Form Size | F3 |
| Grommet Color Code | Brown |
| Hazardous Location Rating | Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2 |
| Hub Size | 3/4" |
| Indoor/outdoor Usage | Indoor/Outdoor |
| Insulated | Yes |
| Ip Rating | IP66 |
| Length - Box To End Of Connector | 1 5/8" |
| Liquid-tight | Yes |
| Material - External Strain Relief | No External Strain Relief |
| Maximum Operating Temperature | 225°F |
| Minimum Operating Temperature | -30°F |
| Nema Rating | NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Number Of Cords | 1 |
| Overall Length | 2 1/8" |
| Resistance Properties | Corrosion Resistant |
| Standards | CSA LR27378, UL E54218(M) |
| Strain Relief Type | No External Strain Relief |
| Thread Gender | Male |
| Thread Type | NPT |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 3.96 |
| Ship length (cm) | 5.46 |
| Ship width (cm) | 3.96 |
| HS code | 3925900000 |
| Country of Origin | CN |
| Product | Model | Color | Conduit Size | Height | Item | Length | Material | Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
SHC1010ZP | Black | 3/8" | - | Liquid Tight Connector | 1 14/64" | Zinc Plated Steel | - | €16.28 | |
 |
SHC1011CR | White | 3/8" | - | Liquid Tight Connector | 1 17/32" | Nylon | - | €14.71 | |
 |
SHC1012CR | Blue | 3/8" | - | Liquid Tight Connector | 1 17/32" | Nylon | - | €14.71 | |
 |
SHC1019CR | Green | 1/2" | - | Liquid Tight Connector | 2 3/64" | Nylon | - | €15.04 | |
 |
SHC1020ZP | Orange | 1/2" | - | Liquid Tight Connector | 1 24/32" | Zinc Plated Steel | - | €16.83 | |
 |
SHC1027ZP | Yellow | 1/2" | - | Liquid Tight Connector | 2 3/64" | Zinc Plated Steel | - | €18.18 | |
 |
SHC1028ZP | Orchid | 1/2" | - | Liquid Tight Connector | 2 3/64" | Zinc Plated Steel | - | €18.18 |
