| Body Color | Black |
| Body Material | Nylon |
| Box Connection | M12 |
| Collar Material | Nylon |
| Compatible Conduit Trade Size | 12 mm |
| Connection Orientation | Straight |
| Cord Dia. Range | 0.12" to 0.25" |
| Environmental Rating | Dust-Tight, General Purpose, Hazardous Location, Liquid Tight |
| For Maximum Cable Od | 1/4" |
| For Minimum Cable Od | 0.12" |
| For Use With | Flexible Cord |
| Grommet Color Code | No Code |
| Grommet Material | Buna N |
| Hazardous Location Rating | Class I, Division 2, Class II, Division 1 and 2, Class III, Division 1 and 2 |
| Hazardous Location Rating - Europe | Not Rated |
| Hub Size | M12 |
| Indoor/outdoor Usage | Indoor/Outdoor |
| Insulated | No |
| Ip Rating | IP66 |
| Length - Box To End Of Connector | 5/8" |
| Liquid-tight | Yes |
| Material - External Strain Relief | No External Strain Relief |
| Maximum Operating Temperature | 225°F |
| Minimum Operating Temperature | -22°F |
| Number Of Cords | 1 |
| Overall Length | 5/16" |
| Series | Low Profile Metric Cord Connectors |
| Standards | CSA, UL |
| Strain Relief Type | No External Strain Relief |
| Thread Gender | Male |
| Thread Type | Metric |
