750mv Compatible | No |
Amazon Alexa Compatible | Yes |
Automatic Changeover | Yes |
Backlit Screen | Yes |
Batteries Included | No |
Battery Backup | No |
Color | White |
Control Type | Touch Screen |
Dehumidification Control | No |
Depth | 6 1/8" |
Display Color | Blue |
Display Type | Backlit |
Dual Transformer Compatible | No |
Electrical Connection Type | Hardwired |
Fan Switching | Yes |
Features | Wifi, Geofence, Programmable, Universal Mounting |
Filter Change Reminder | No |
Filter Indicator | No |
Google Home Compatible | No |
Green Certification Or Other Recognition | Energy Star |
Height | 2 1/4" |
Housing Color | White |
Humidification Control | No |
Includes Batteries | No |
Includes Positive Off | Yes |
Key Pad Lockout | No |
Low-battery Indicator | No |
Maximum Operating Humidity | 90% |
Millivolt Compatible | No |
Minimum Operating Humidity | 5% |
Mounting Direction | Horizontal |
Mounting Location | Wall |
Number Of Heating Stages (conventional System) | 2 |
Overall Depth | 1 7/16" |
Overall Height | 4 1/16" |
Overall Width | 4 1/16" |
Programmable Fan | Yes |
Remote Sensing Capability | Yes |
Shape | Square |
Smart Capabilities | Geofencing, Voice Enabled |
Smart Connectivity | Cellular Control, Wi-Fi Assistant Enabled, Wi-Fi Control |
Stages Cool | 2 |
System Settings | Auto-Cool-Emergency Heat-Heat-Off |
Temperature Limiting | No |
Temperature Readout | Yes |
Temporary Program Override | Yes |
Temporary Temperature Hold | Yes |
Type | Low Voltage |
Wi-fi Frequency | 2.4 GHz |
Width | 5 1/8" |
Wifi Capability | Yes |
Application | Heat And Cool |
Changeover Type | Automatic and Manual |
Compatible Software/device | Amazon Alexa, Apple Homekit, Cortana, Google Assistant, IFTTT |
Compatible System Type | Electric Forced Air Furnaces, Gas Forced Air Furnaces, Heat Pump With Aux |
Fan Settings | Auto On Circulate |
Frequency | 50/60 Hz |
Includes | Anchors, Installation (J-box) Adaptor, Screws, Small Decorative Cover Plate, UWP Mounting System |
Low Battery Indicator | No |
Maximum Temperature Control | 102°F |
Minimum Temperature Control | 37°F |
Number Of Cooling Stages - Conventional System | 2 |
Number Of Cooling Stages - Heat Pump System | 1 |
Number Of Heating Stages - Conventional System | 2 |
Number Of Heating Stages - Heat Pump System | 2 |
Number Of Zones | 1 |
Occupancy Sensor | Compatible with Occupancy Sensor |
Programming Capability | 5-1-1, 5-2, 7-Days |
Stages Conventional | 2 H / 2 V Conventional |
Stages Heat Pump | 2 H/1 C Heat Pump |
Stages Heating/cooling | 2 H/2 V Conventional, 2 H/1 C Heat Pump |
Standards | ENERGY STAR |
Temperature Differential | 1°F |
Temperature Scale | Fahrenheit/Celsius |
Temperature Settings Per Day | 0, 1, 2, 4 |
Terminal Designations | E, G, L/A, O/B, U/U, W, W2, Y, Y2 |
Voltage | 20-30V AC |
Wi-fi Specifications | 802.11B, 802.11G, 802.11N |
