| Item | Direct Coupled Actuator |
| Application | Damper And Valve |
| Contact Form | SPST |
| Control Signal | On/Off |
| Electrical Connection Type | Screw Terminals |
| Includes | Internal End Switch, Self Centering Shaft Adapter |
| Input Voltage | 100-250V AC |
| Ip Rating | IP54 |
| Maximum Operating Temperature | 149°F |
| Minimum Operating Temperature | -22°F |
| Mounting Type | Direct Mount |
| Number Of Auxiliary Switches | 1 |
| Overall Depth | 3 1/8" |
| Overall Height | 7" |
| Overall Width | 3 5/8" |
| Plenum Rating | Plenum Rated |
| Product Type | Actuator |
| Rated Torque | 27 lbs.-in. |
| Return Action | Spring Return |
| Shaft Rotation | CW/CCW |
| Shaft Type | Self Centering |
| Standards | C-TICK N314, CE 2006/95/EC, CE EMC 2004/108/EC, IEC 60730-1, PART 2-14, UL (C-UL) LISTED, UL 873, UL1097 |
| Stroke Degree | 95° |
| System Application | Ball Valves, Butterfly Valves, Cage Valves, Dampers, Globe Valves |
| Time To Close | 60 sec. |
| Ship weight (kg) | 1.73 |
| Ship height (cm) | 17.78 |
| Ship length (cm) | 7.94 |
| Ship width (cm) | 9.21 |
| Country of Origin | MX |
| Model | Item | Price | |
|---|---|---|---|
| 50005859-001/U | Direct Coupled Actuator | €1,060.57 | RFQ
|
| MS7520A2007/U | Actuator | €632.91 | RFQ
|
| MS7520A2205/U | Actuator | €773.70 | RFQ
|
| MS7520W2007/U | Actuator | €476.52 | RFQ
|
| MS7520W2205/U | Actuator | €723.69 | RFQ
|
| MS7505A2030/U | Actuator | €420.47 | RFQ
|
| MS7505A2130/U | Actuator | €575.14 | RFQ
|
