| 3-a Compliance | Not Rated |
| Ball Material | PVC |
| Ball Opening Size | 0.53" |
| Ball Port Style | Full Port |
| Body Material | PVC |
| Coefficient Of Volume (cv) | 1 |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1/4" |
| Connection Size - Side 2 | 1/4" |
| Connection Type - Side 1 | True Union Socket/True Union NPT |
| Connection Type - Side 2 | Socket |
| For Media | Corrosive Chemicals, Water |
| Handle | Locking Tee |
| Handle Color | Red |
| Handle Length | 3 1/2" |
| Handle Material | Glass Filled Polypropylene |
| Included Mounting | ISO 5211 Actuator Mounting Pad |
| Manufacturer Warranty | 3 yrs. |
| Max. Pressure (combustible Gas) | Not Rated |
| Max. Pressure (cwp) | 250 psi |
| Media Temp. Range | 34°F to 140°F |
| Nominal Valve Size | 1/4" |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Overall Length | 6.65" |
| Seal Material | FKM |
| Seat Material | PTFE |
| Special Features | Actuator Compatible |
| Standards | ASTM D1784 CELL CLASS 12454, ASTM D4101 CELL CLASS 85580, NSF/ANSI 372 |
| Stem Material | PVC |
| Stem Type | Blowout Resistant |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Straight |
| Valve Construction | Three-Piece |
| Valve Series | TBH |
| Vented Ball Valve | Non Vented |
