| Application | Industrial Use |
| Body Material | Polypropylene |
| Bonnet Material | PPE |
| Connection Type | NPT x NPT |
| Factory Set Pressure | 50 psi |
| Inlet Connection Size | 3/4" |
| Max. Continuous Flow Rate | 19.2 GPM |
| Max. Intermittent Flow Rate | 6.2 GPM |
| Max. Operating Temperature | 180°F |
| Nsf Certifications | NSF 61, NSF 372 |
| Operating Pressure Range | 5 psi to 150 psi |
| Outlet Connection Size | 3/4" |
| Overall Height | 5 9/16" |
| Overall Width | 3 1/2" |
| Port Design | Reduced Port |
| Pressure Adjustment Range | 10 psi to 150 psi |
| Seal Material | PTFE |
| Standards | ANSI 372, ANSI 61 |
| Valve Type | Back Pressure |
| Ship weight (kg) | 0.83 |
| Country of Origin | US |
