| Body Material | PVC |
| Coefficient Of Volume(cv) | 10 |
| Connection Type | NPT x Socket |
| Connection Type - Side 2 | Socket |
| Connection Type-side 1 | NPT |
| Diaphragm Material | EPDM, PTFE |
| For Media | Chemicals |
| Handle Height | 4.33" |
| Handle Type | Wheel |
| Length | 5.2" |
| Manufacturer Warranty | 3 yrs. |
| Max Pressure (cwp) | 150 psi |
| Max. Operating Temperature | 140°F |
| Media Temp. Range | 34°F to 140°F |
| Min. Operating Temperature | 34°F |
| Nominal Valve Size | 1" |
| Seal Material | FPM |
| Special Features | Position Indicator |
| Standards | ASTM D1784 |
| Valve Series | DAB |
| Valve Ways | 2-Way |
| Ship weight (kg) | 1.26 |
| Country of Origin | US |
