| Ball Material | PVC |
| Body Material | PVC |
| Connection Type | True Union Socket/True Union NPT |
| For Media | Corrosive Chemicals, Water |
| Max. Pressure (cwp) | 250 psi |
| Mount Type | Integral |
| Operating Temp. Range | 60°F to 150°F |
| Pipe Size | 1/2" |
| Seal Material | FPM |
| Seat Material | PTFE |
| Standards | ASTM D1784 CELL CLASS 12454, ASTM D4101 CELL CLASS 85580, NSF/ANSI 61 |
| Stem Material | PVC |
| V-port Angle | 90° |
| Ship weight (kg) | 0.45 |
| Ship length (cm) | 16.89 |
| Country of Origin | US |
