GRAINGER P25S-RY060R-16 Kingpinless Swivel Plate Caster, 6 Inch, Light-Medium Duty, 500 Lbs Load Rating
€75.68 /unit
Request a Quote
Payment
Payment
| Item | Plate Caster |
| Bearing Type | Single Ball |
| Brake Type | Side Thumbscrew |
| Caster Brake Included | No |
| Caster Material | Rubber |
| Caster Product Group | Kingpinless Caster |
| Caster Temp. Range Available | Yes |
| Caster Type | Kingpinless Swivel |
| Caster Wheel Material | Rubber |
| Caster Wheel Shape | Standard |
| Core Color | Silver |
| Core Material | Cast Iron |
| Durometer | 70 Shore A |
| Extended Lead | No |
| Frame Finish | Zinc Plated |
| Frame Material | Steel |
| Hole Pattern | A |
| Inside Bolt Hole Spacing | 2 7/16" x 4 15/16" |
| Load Rating | 500 lbs. |
| Lock Type | No Lock Included |
| Max. Temp. | 180°F |
| Min. Temp. Rating | -40°F |
| Mounting Bolt Dia. | 1/2" |
| Non-marking | No |
| Number Of Wheels | 1 |
| Outside Bolt Hole Spacing | 3 3/8" x 5 1/4" |
| Overall Height | 7 1/2" |
| Plate Size | 4 1/2" x 6 1/4" |
| Raceway Type | Single Ball |
| Swivel Radius | 4 3/4" |
| Wheel Bearing Type | Roller |
| Wheel Bearings | Roller |
| Wheel Color | Black |
| Wheel Diameter | 6" |
| Wheel Width | 2" |
| Application | Dollies, Floor Trucks, Shop Carts, Warehouse Trucks, Waste Disposal Trucks |
| Caster Brake Type | No Brake Included |
| Caster Frame Material | Steel |
| Caster Sub-type | Swivel |
| Features | Noise Reduction |
| Includes | Complete Caster |
| Includes Thread Guards | No |
| Mounting Height | 7 1/2" |
| Mounting Plate Bolt Hole Pattern | A |
| Mounting Plate Size | 4 1/2" x 6 1/4" |
| Mounting Plate Size & Bolt Hole Pattern | 4 1/2" x 6 1/4" ( A ) |
| Number Of Mounting Holes | 4 |
| Standards | ICWM |
| Swivel Construction | Kingpinless |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Single Ball |
| Tread Shape | Standard |
| Wheel Core Material | Cast Iron |
| Wheel Dia. | 6" |
| Wheel/tread Color | Black |
| Wheel/tread Hardness | 65 Shore A |
| Wheel/tread Hardness Rating | Soft |
| Wheel/tread Material | Rubber |
| Ship weight (kg) | 3.6 |
| Product | Model | Bearing Type | Brake Type | Caster Brake Included | Caster Load Rating Range | Caster Product Group | Caster Temp. Range Available | Caster Type | Caster Wheel Material | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
400K28 | - | Total Lock | Yes | Light-Medium Duty | Swivel Caster with Total Lock | Yes | Swivel | Thermoplastic Rubber | 1 | €60.39 | RFQ
|
 |
400K43 | Roller | Side Pedal Brake | - | - | - | - | - | - | 1 | €32.91 | |
 |
400K47 | Roller | Total Lock Brake | - | - | - | - | - | - | 1 | €36.05 | |
 |
400K48 | Roller | - | - | - | - | - | - | - | 1 | €26.14 | |
 |
400K58 | Plain | - | - | - | - | - | - | - | 1 | €13.73 | |
 |
400K59 | - | - | - | - | - | - | - | - | 1 | €15.47 | |
 |
400K60 | Delrin | - | - | - | - | - | - | - | 1 | €11.81 |
