| Item | Pulley Block |
| Attachment Type | Flat Mount |
| Bearing Type | Plain |
| Designed For | Wire Rope |
| Eye Hook Inside Dia. | None |
| Finish | Zinc Plated |
| Length | 2.562" |
| Max. Cable Size | 1/4" |
| Mounting Hole Dia. | 0.188" |
| Rope Dia. | 1/4" |
| Sheave Inside Dia. | 1/2" |
| Sheave Material | Steel |
| Sheave Outside Dia. | 3" |
| Sheave Width | 0.469" |
| Width | 3.562" |
| Working Load Limit | 800 lbs. |
| Compatible Rope Diameter | 1/4" |
| Compatible Rope Type | Wire Rope |
| Housing Material | Carbon Steel |
| Mount Type | Upright Mount |
| Mounting Hole Diameter | 3/16" |
| Number Of Grooves | 2 |
| Operation | Pulling |
| Overall Depth | 1 1/4" |
| Overall Height | 3 5/8" |
| Overall Hxw | 3 5/8" x 3 1/8" |
| Overall Width | 3 1/8" |
| Product Type | Pulley Block |
| Pulley Type | Mounted |
| Sheave Depth | 7/16" |
| Sheave Inside Diameter | 2 1/2" |
| Sheave Outside Diameter | 3" |
| Standards | ASME B30.26 |
| Ship weight (kg) | 0.84 |
| Ship height (cm) | 9.21 |
| Ship length (cm) | 3.18 |
| Ship width (cm) | 7.94 |
