FRIEDRICH FPHFD12A3A Split System Condenser With Heat Pump, 12000 BTUH, 208/230VAC
Get it by Tuesday, Jun 17
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Condenser |
| Air Flow Rate | 235/285/335 CFM |
| Amps | 8.6A |
| Area | 450 sq. ft. to 550 sq. ft. |
| Capacity | 12000 btuH |
| Compressor Type | Rotary |
| Connectivity | Wifi Control |
| Control Type | Electronic |
| Control Volts | 12V DC |
| Cooling Capacity | 12000 btuH |
| Dehumidification Rate | 3 |
| Depth | 16 1/2" |
| Eer | 11 |
| Frequency | 60 Hz |
| Fuse Amps | 30A |
| Head Height | 22 1/4" |
| Head Width | 42 1/2" |
| Height | 25" |
| Hspf | 10 |
| Line Length | 82 ft. |
| Number Of Speeds | 3 |
| Operation Mode | Cooling, Heating |
| Phase | 1 |
| Size | 1/4" |
| Sound Level | 54 dBA |
| Warranty | 5 yrs. |
| Wattage | 2500 W |
| Width | 37" |
| Air Flow | 235/285/335 CFM |
| Control Voltage | 12V DC |
| Heating Capacity - Heat Pump | 14400 btuH |
| Heating Method | Heat Pump |
| Heating Watts | 2500 W |
| Hz | 60 Hz |
| Indoor Head Depth | 17 5/8" |
| Indoor Head Height | 7 1/2" |
| Indoor Head Mounting | Concealed Duct |
| Indoor Head Width | 35 7/8" |
| Indoor Sound Level | 36/33/30 dBA |
| Key Features | WiFi Capable |
| Liquid Line Size | 1/4" |
| Manufacturers Warranty Length | 5 yrs. |
| Max. Line Length - Total System | 82 ft. |
| Max. Time Delay Fuse Amps | 30A |
| Max. Vertical Line Length | 49 ft. |
| Min./max. Line Length - Single Run | 82 ft. |
| Number Of Indoor Units Supported | 1 |
| Operation Mode - Hvac | Cooling/Heating |
| Outdoor Sound Level | 54 dB |
| Product Type | Air Handler Only |
| Programming Capability | Daily Schedules |
| Refrigerant Precharge | 25 oz. |
| Refrigerant Type | R-410A |
| Remote Control Functions | Full Function |
| Requires | Power and Communication Cable, Refrigerant Line Set for New Installation |
| Seacoast Corrosion Protection | Front and Rear Coil |
| Seer | 19 |
| Smart Connectivity | Wi Fi |
| Standards | AHRI, ETL |
| Suction Line Size | 3/8" |
| Voltage | 208/230V AC |
| Ship weight (kg) | 21.92 |
| Ship height (cm) | 63.5 |
| Ship length (cm) | 41.91 |
| Ship width (cm) | 93.98 |
| Country of Origin | CN |
| Product | Model | Air Flow | Amps | Area (square-ft.) | Capacity | Depth | Head Width | Height | Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
FPHFD18A3A | 370/440/529 cfm | 14.6A | 700 to 1000 sq. ft. | 18000 BTUH | 28 3/4" | 53" | 17 3/4" | 3/8" | €1,606.13 |
