| Item | Motor |
| Ambient Temperature | 60C |
| Ce | N |
| Csa | Y |
| Current | 2.6 A |
| Drive End Bearing | Ball |
| Duty | Continuous |
| Electrical Type | Permanent Split Capacitor |
| Enclosure | Totally Enclosed Air Over |
| Frame | 48 |
| Frame Length | 4.45 in |
| Frame Material | Rolled Steel |
| Frequency | 60 Hz |
| Insulation Class | B |
| Mounting | Extended Studs |
| Number Of Speeds | 1 |
| Opp Drive End Bearing | Ball |
| Output Hp | 1/3 Hp |
| Output Kw | 0.25 kW |
| Phase | 1 |
| Poles | 6 |
| Rotation | Reversible |
| Service Factor | 1 |
| Shaft Diameter | 0.500 in |
| Shaft Extension | 6.50 in |
| Shaft Type | Double Flat |
| Speed | 1075 rpm |
| Starting Method | Across The Line |
| Thermal Protection | Automatic |
| Ul | Recognized |
| Voltage | 208-230 V |
| Ship weight (kg) | 6.03 |
| Ship height (cm) | 14.61 |
| Ship length (cm) | 27.94 |
| Ship width (cm) | 14.61 |
| Country of Origin | TH |
