| Item | Motor |
| Motor Design | Permanent Split Capacitor |
| Motor Service Factor | 1 |
| Motor Shaft Rotation | Counterclockwise Shaft End |
| Motor Thermal Protection | Automatic |
| Number Of Shafts | 1 |
| Ambient Temperature | 40C |
| Ce | N |
| Csa | Y |
| Current | 0.80 A |
| Drive End Bearing | Sleeve |
| Duty | Continuous |
| Electrical Type | Permanent Split Capacitor |
| Enclosure | Open Air Over |
| Frame | 42 |
| Frame Length | 3.13 in |
| Frame Material | Rolled Steel |
| Frequency | 60 Hz |
| Insulation Class | B |
| Mounting | Extended Studs |
| Number Of Speeds | 2 |
| Opp Drive End Bearing | Sleeve |
| Output Hp | 1/15 Hp |
| Output Kw | 0.05 kW |
| Overall Length | 25.45 in |
| Phase | 1 |
| Poles | 6 |
| Rotation | Counterclockwise Shaft End |
| Service Factor | 1 |
| Shaft Diameter | 0.500 in |
| Shaft Extension | 10.5 in |
| Shaft Type | Flat |
| Speed | 1100 rpm |
| Starting Method | Across The Line |
| Thermal Protection | Automatic |
| Ul | Recognized |
| Voltage | 115 V |
| Ship weight (kg) | 4.95 |
| Ship height (cm) | 69.85 |
| Ship length (cm) | 16.51 |
| Ship width (cm) | 15.88 |
| Country of Origin | MX |
