ENERPAC SWI2025TESTDSPB Innovative Hydraulic Flange Spreading Wedge, Standard Kit
Get it by Tuesday, Jun 17
€5,422.23 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Flange Wedge |
| Application | For Flange Spreading |
| Capacity (imperial Tons) | 27 |
| Capacity (kn) | 240 |
| Capacity (metric Tons) | 24 |
| Includes | Carrying Case, Hand Pump with Gauge, Hydraulic Cylinder, Hydraulic Hose with 90° Elbow, Lanyard, Pair of Stepped Blocks, Set of Safety Block, Wedgehead |
| Jaw Width (in) | 700 |
| Jaw Width (mm) | 60,0 |
| Max. Lift Per Stage | 3.38" |
| Max. Pressure | 10000 psi |
| Maximum Operating Pressure (psi) | 10,000 |
| Maximum Spread (in) | 4.1 |
| Maximum Spread (mm) | 103.5 |
| Model Type | Single Wedge and Pump Set |
| Nominal Capacity | 24 ton. |
| Power Source | External Hydraulic |
| Single Acting/double Acting | Single Acting |
| Spread Width | 4.1" |
| Spreader Certification | Not Atex certified |
| Tip Clearance | 1/4" |
| Tip Clearance (in) | 0.24 |
| Tip Clearance (mm) | 6 |
| Ship weight (kg) | 20.52 |
| Ship height (cm) | 33.02 |
| Ship length (cm) | 57.91 |
| Ship width (cm) | 16.51 |
| Country of Origin | UK |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
SWI2025TEMAXEX | Flange Wedge | €10,762.29 | |
 |
SWI2025TEMAXSPB | Flange Wedge | €9,965.34 | |
|
SWI2025TEMINEX | Flange Wedge | €4,300.56 | |
|
SWI2025TEMINSPB | Flange Wedge | €4,032.27 | |
|
SWI2025TESTDEX | Flange Wedge | €5,828.13 | |
 |
SWI2025TISTDEX | Flange Wedge | €5,828.13 | |
 |
SWI5TE-S | Flange Wedge | €2,428.47 |
