| Item | Hydraulic Electric Pump |
| Application | Dump and Hold |
| Current Drawn | 9.5A |
| Cylinder Compatibility | Single Acting |
| Dimension A | 14.5" |
| Dimension B | 12.18" |
| Dimension C | 14.72" |
| Dimension D | 4.15" |
| Dimension E | 5.12" |
| Dimension F | 12.74" |
| Dimension H | 0.4" |
| Dimension J | 5.62" |
| Duty Cycle | Intermittent |
| Frequency | 50/ 60 Hz |
| Max. Flow at Rated Pressure | 20 cu. in./min. |
| Max. Operating Pressure | 10000 psi |
| Motor HP | 0.5 hp |
| Output Flow Rate 1st Stage | 200 cu. in./min. |
| Output Flow Rate 2nd Stage | 20 cu. in./min. |
| Power Source | Electric |
| Pressure Rating 1st Stage | 200 psi |
| Pressure Rating 2nd Stage | 10000 psi |
| Product Datasheet | enerpac-pud1100e.pdf |
| Pump Control | Pendant |
| Reservoir Capacity | 231 cu. in. |
| Sound Level | 85 dBA |
| Usable Oil Capacity | 1 gal. |
| Valve Function | Advance/ Hold/ Retract |
| Valve Operation | Solenoid |
| Valve Type | 3-Way, 2-Position |
| Voltage | 115V |
| Ship weight (kg) | 17.6 |
| Ship height (cm) | 43.51 |
| Ship length (cm) | 40.74 |
| Ship width (cm) | 30.63 |
| HS code | 8413500050 |
| Model | Dimension J | Application | Dimension A | Valve Function | Dimension B | Dimension C | Dimension D | Dimension E | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| PUD1101B | 5.62" | Dump | 14.5" | Advance/ Retract | 12.18" | 14.72" | 4.15" | 5.12" | €6,653.13 | |
| PUD1300B | 5.25" | Dump and Hold | 9.62" | Advance/ Hold/ Retract | 9.62" | 14.25" | 4" | 4.72" | €7,011.03 | |
| PUD1100B | 5.25" | Dump | 9.62" | Advance/ Retract | 9.62" | 14.25" | 4" | 4.72" | €6,630.65 | |
| PUD1100E | - | - | - | - | - | - | - | - | €6,872.25 | |
| PUD1101E | - | - | - | - | - | - | - | - | €7,125.40 | |
| PUD1300E | - | - | - | - | - | - | - | - | €6,927.42 | |
| PUD1301E | - | - | - | - | - | - | - | - | €7,182.19 |
