ENERPAC FA9TESTD Steel Flange Alignment Tool, Size 25-53/64 x 3-15/16 x 18-1/2 Inch
Get it by Tuesday, Jun 17
€7,788.33 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Flange Alignment Tool Set |
| Application | Lift, Lower |
| Bolt Hole Dia. (in.) | 1 2/5" |
| Case Dimensions | 36.2" x 20.5" x 8.3" |
| Hole Size | 1.406" |
| Material | Steel |
| Max. Bolt Dia. | Not Applicable |
| Max. Reaction Force | 10.1 ton. |
| Maximum Flange Thickness | 9" |
| Min. Bolt Size | 1 2/5" |
| Overall Height | 18 1/2" |
| Overall Length | 25.828" |
| Overall Width | 3.938" |
| Promotion Restriction | Not Eligible For Promotion |
| Spread | 10" |
| Includes | 10, 000 psi Sealed Hand Pump with Gauge, 2 m 10, 000 psi Hydraulic Hose, Carry Case, Hydraulic Cylinder, Instruction Manual, Ratchet Strap |
| Maximum Flange Capacity | 10.1 ton. |
| Minimum Bolt Diameter | 1 3/8" |
| Minimum Flange Thickness | 3 5/8" |
| Product Type | Hydraulic Flange Alignment Tool |
| Tool Height | 18 1/2" |
| Tool Length | 25 13/16" |
| Tool Series | FA |
| Tool Weight | 32 lbs. |
| Tool Width | 3 15/16" |
| Ship weight (kg) | 28.35 |
| Ship height (cm) | 47.09 |
| Ship length (cm) | 65.58 |
| Ship width (cm) | 65.61 |
| Country of Origin | UK |
