ENERPAC A61 Hydraulic Manifold, 6.5 Inch Long, 7 Port
Get it by Wednesday, Jun 18
€297.00 /unit
Add To Cart
Request a Quote
Payment
Get it by Wednesday, Jun 18
Payment
| Item | Hydraulic Manifold |
| Body Material | Aluminum |
| Dimension A | 6 1/2" |
| Dimension B | 1 1/4" |
| Dimension C | 1 1/4" |
| Dimension D | 7/25" |
| Dimension D1 | 1 1/2" |
| Dimension D2 | 1 1/4" |
| Dimension F | 1" |
| Dimension F1 | 1 1/4" |
| For Media | Oil |
| Grade | Grade 7075 |
| Material | Aluminum |
| Max. Operating Pressure | 10000 psi , 5000 psi |
| Mount Hole Size | 7/25" |
| No. Of Stations | 7 |
| Number Of Ports | 7 |
| Number Of Stations | 7 |
| Overall Height | 1 1/4" |
| Overall Length | 6 1/2" |
| Overall Width | 1 1/4" |
| Port Connection Gender | Female |
| Port Size | #4 |
| Promotion Restriction | Not Eligible For Promotion |
| Temp. Range | +32°F to +180°F |
| Type | Seven Port Bar |
| Fluid Service | Oil |
| Maximum Pressure | 5000 psi |
| Mounting Hole Size | 0.28" |
| Operating Temperature - Maximum | 180°F |
| Operating Temperature - Minimum | 32°F |
| Port Connection Size | #4 |
| Port Connection Type | SAE 45°Flare |
| Series | A |
| Ship weight (kg) | 0.48 |
| Ship height (cm) | 8.89 |
| Ship length (cm) | 24.38 |
| Ship width (cm) | 9.4 |
| HS code | 8481200050 |
| Country of Origin | US |
