Get it by Thursday, Jun 19
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
Payment
| Item | Overload Protector |
| Accessory Type | Manual Motor Protector Base |
| Amps | 65A |
| Depth | 7 9/25" |
| Description/special Features | Electronic Manual Motor Protector Base With Plug In Trip Unit, 41 Overcurrent Setting Range, Selectable Trip Class, Interchangeable Trip Units |
| Frame Size | B |
| Height | 6.3" |
| Horsepower @ Single Phase - 240v Ac | 7 1/2 hp |
| Horsepower @ Three Phase - 208v Ac | 15 hp |
| Horsepower @ Three Phase - 600v Ac | 40 hp |
| Hp @ 1 Phase - 115v | 3 hp |
| Hp @ 1 Phase - 230v | 7 1/2 hp |
| Hp @ 3 Phase - 200v | 15 hp |
| Hp @ 3 Phase - 240v | 15 hp |
| Hp @ 3 Phase - 460-575v | 40 hp |
| Hp @ 3 Phase - 480v | 40 hp |
| Hp @ 3 Phase - 575v | 40 hp |
| Number Of Poles | 3 |
| Operator | Selector Switch |
| Overall Depth | 7 1/2" |
| Overall Height | 1 4/5" |
| Overall Width | 6" |
| Product Height | 1 4/5" |
| Product Length/depth | 7 1/2" |
| Product Width | 6" |
| Starter Type | Manual |
| Type | Base |
| Width | 2.17" |
| Compatible With Series | Series XT IEC |
| Current Ac | 65A |
| Horsepower @ Three Phase - 240v Ac | 15 hp |
| Horsepower @ Three Phase - 480v Ac | 40 hp |
| Maximum Voltage Rating | 600V AC |
| Standards | UL LISTED |
| Ship weight (kg) | 1.35 |
| Ship height (cm) | 4.57 |
| Ship length (cm) | 19.05 |
| Ship width (cm) | 15.24 |
| Country of Origin | DE |
| Model | Item | Price | |
|---|---|---|---|
| XTPB001BC1 | Manual Motor Protector | €340.73 | |
| XTPB004BC1 | Manual Motor Protector | €362.50 | |
| XTPB010BC1 | Manual Motor Protector | €336.51 | |
| XTPB012BC1 | Manual Motor Protector | €380.27 | |
| XTPB016BC1 | Manual Motor Protector | €384.03 | |
| XTPB020BC1 | Manual Motor Protector | €382.09 | |
| XTPB025BC1 | Manual Motor Protector | €418.55 |
