| Item | Socket Head Cap Screw |
| Drive Size | 9/16" |
| Drive Type | Hex Socket |
| Finish | Black Oxide |
| Hardness | Rockwell C37-C44 |
| Head Dia. | 1.688" |
| Head Height | 0.468" |
| Head Type | Flat |
| Length | 4" |
| Material | Steel |
| Min. Tensile Strength | 135000 psi |
| System Of Measurement | Imperial |
| Temp. Range | -65°F to +300°F |
| Thread Direction | Right Hand |
| Thread Length | 2 1/4" |
| Thread Size | 7/8"-9 |
| Thread Style | Partially Threaded |
| Thread Type | Coarse |
| Combined Material & Grade | Grade Alloy Steel |
| Countersink Angle | 82° |
| Dimensional Standards | ASME B18.3 |
| Display Qty | 1 |
| Head Diameter | 1.688" |
| Material Quality Standards | ASTM F835 |
| Material Type | Steel |
| Maximum Temperature | 300°F |
| Minimum Temperature | -65°F |
| Minimum Thread Length | 2 1/4" |
| Screw Length | 4" |
| Tensile Strength | 135000 psi |
| Thread Fit | 3A |
| Ship weight (kg) | 0.29 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 11.43 |
| Ship width (cm) | 5.59 |
| HS code | 7318158020 |
