| Aircraft Drill | No |
| Application | Holemaking |
| Coolant Fed | Non-Coolant Through |
| Cutting Direction | Right Hand |
| Drill Length Class | Stub Length |
| Flute Type | Straight |
| List Number | 1766 |
| Primary Material Application | Cast Iron, Steel |
| Primary Material Application Iso Code | K, P |
| Secondary Material Application | Aluminium, Brass, Bronze, Copper, Stainless Steel, Steel |
| Secondary Material Application Iso Code | M, N, P |
| Sheeter Drill | No |
| Decimal Equivalent | 0.1015 |
| Drill Bit Point Angle | 140° |
| Drill Bit Point Type | Radial Point |
| Drill Bit Size | #38 |
| Drill Diameter Tolerance | 0"/-0.0005" |
| Finish - Machining | Bright (Uncoated) |
| Flute Length | 0.813" |
| Helix Angle | 0° |
| Material - Machining | Carbide |
| Measurement System | Wire |
| Number Of Flutes | 2 |
| Overall Length | 1.813" |
| Shank Dia. | 0.1015" |
| Shank Length | 1" |
| Shank Type - Machining | Straight |
| Standards | ASME B94.11M |
| Ship length (cm) | 4.61 |
| Country of Origin | US |
