| Coolant Fed | Non-Coolant Through |
| Cutting Direction | Right Hand |
| Flute Type | Spiral |
| Grade | General Purpose |
| Helix Angle | +21° to +34° |
| List Number | 1894 |
| Primary Material Application | Alloy Steel, Carbon Steel, Gray Cast Iron, Low Carbon Steel, Nodular Cast Iron |
| Primary Material Application Iso Code | K, P |
| Spiral Direction | Right Hand |
| System Of Measurement | Decimal Inch |
| Taper Shank Description | Morse Taper |
| Decimal Equivalent | 0.5625 |
| Drill Bit Point Angle | 118° |
| Drill Bit Point Type | Radial Point |
| Drill Bit Size | 9/16" |
| Drill Diameter Tolerance | 0"/-0.0012" |
| Finish - Machining | Steam Oxide |
| Flute Length | 4 7/8" |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | General Purpose |
| Maximum Drilling Depth | 4 7/8" |
| Measurement System | Decimal Inch |
| Number Of Flutes | 2 |
| Overall Length | 8 3/4" |
| Shank Type - Machining | Taper |
| Standards | ASME B94.11M |
| Taper Shank Size | #2 |
| Ship weight (kg) | 0.24 |
| Ship length (cm) | 22.23 |
| Country of Origin | US |
