| Coolant Fed | Non Coolant Through |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.234 |
| Drill Bit Point Angle | 118° |
| Drill Bit Point Type | Radial Point |
| Drill Bit Size | A |
| Drill Diameter Tolerance | 0"/-0.001" |
| Drill Length Class | Jobber Length |
| Finish - Machining | TiN |
| Flute Length | 2 5/8" |
| Flute Type | Spiral |
| Helix Angle | 21° to 34° |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | General Purpose |
| Maximum Drilling Depth | 2 5/8" |
| Measurement System | Decimal Inch |
| Number Of Flutes | 2 |
| Overall Length | 3.875" |
| Primary Material Application | Alloy Steel, Aluminum, Carbon Steel, Gray Cast Iron, Low Carbon Steel, Nodular Cast Iron |
| Primary Material Application Iso Code | K, N, P |
| Secondary Material Application | Alloy Steel, Aluminum, Carbon Steel, Gray Cast Iron, Low Carbon Steel, Nodular Cast Iron |
| Shank Length | 1.2500" |
| Shank Type - Machining | Straight |
| Spiral Direction | Right Hand |
| Standards | ASME B94.11M, DIN 338 |
