| Coolant Fed | Non Coolant Through |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.2380 |
| Drill Bit Point Angle | 135° |
| Drill Bit Point Type | Split Point |
| Drill Bit Size | B |
| Drill Diameter Tolerance | 0"/-0.001" |
| Drill Length Class | Screw Machine Length |
| Finish - Machining | Steam Oxide |
| Flute Length | 1.375" |
| Flute Type | Spiral |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | Heavy Duty |
| Maximum Drilling Depth | 1 3/8" |
| Measurement System | Decimal Inch |
| Number Of Flutes | 2 |
| Overall Length | 2.5" |
| Primary Material Application | Alloy Steel, Carbon Steel, Gray Cast Iron, Low Carbon Steel, Nodular Cast Iron |
| Primary Material Application Iso Code | H, K, M, P, S |
| Shank Diameter | 15/64" |
| Shank Length | 1.1250" |
| Shank Type - Machining | Straight |
| Spiral Direction | Right Hand |
| Standards | ASME B94.11M |
| Ship weight (kg) | 0.13 |
| Ship length (cm) | 6.35 |
| Country of Origin | US |
