| Aircraft Drill | No |
| Coolant Fed | Non-Coolant Through |
| Cutting Direction | Right Hand |
| Drill Bit Dimension Type | Wire |
| Drill Bit Grouping | Drill Bit |
| Drill Length Class | Jobber Length |
| Flute Type | Spiral |
| Helix Angle | +21° to +34° |
| List Number | 1898 |
| Max. Drilling Depth | 1 13/32" |
| Primary Material Application Iso Code | K, N, P |
| Sheeter Drill | No |
| Spiral Direction | Right Hand |
| Web Thinning | Thinned |
| Decimal Equivalent | 0.147 |
| Depth:dia. Ratio | 4xD |
| Drill Bit Point Angle | 118° |
| Drill Bit Point Type | Conventional Point |
| Drill Bit Size | #26 |
| Drill Diameter Tolerance | 0"/-0.0007" |
| Drill Point Length | 0.0442" |
| Finish - Machining | Bright (Uncoated) |
| Flute Length | 1 7/8" |
| Material - Machining | High Speed Steel |
| Maximum Drilling Depth | 1 13/32" |
| Measurement System | Wire |
| Number Of Coolant Holes | 0 |
| Number Of Flutes | 2 |
| Overall Length | 3" |
| Primary Material Application | Aluminum and Non Ferrous Material, Cast Iron, Steel |
| Series | 1898 Series |
| Shank Length | 1 1/8" |
| Shank Type - Machining | Straight |
| Standards | ASME B94.11M |
| Ship length (cm) | 7.62 |
| Country of Origin | US |
