| Aircraft Drill | No |
| Application | For Alloy, Carbon Free Machining And Tool Steels |
| Coolant Fed | Non-Coolant Through |
| Coolant Through | No |
| Cutting Direction | Right Hand |
| Drill Bit Dimension Type | Fractional Inch |
| Drill Bit Grouping | Drill Bit |
| Drill Length Class | Jobber Length |
| Flute Type | Spiral |
| Grade | High Performance |
| Helix Angle | +35° to +45° |
| Left/right Hand | Right |
| Material | High Speed Steel |
| No. Of Pieces | 1 |
| Primary Material Application | Steel |
| Primary Material Application Iso Code | P |
| Sheeter Drill | No |
| Spiral Direction | Right Hand |
| System Of Measurement | Fractional Inch |
| Web Thinning | Thinned |
| Decimal Equivalent | 0.2344 |
| Depth:dia. Ratio | 8xD |
| Drill Bit Point Angle | 135° |
| Drill Bit Point Type | Split Point |
| Drill Bit Size | 15/64" |
| Drill Diameter Tolerance | 0"/-0.0007" |
| Drill Point Length | 0.0485" |
| Finish - Machining | TiCN |
| Flute Length | 2 5/8" |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | High Performance |
| Maximum Drilling Depth | 1 31/32" |
| Measurement System | Fractional Inch |
| Number Of Coolant Holes | 0 |
| Number Of Flutes | 2 |
| Overall Length | 3 7/8" |
| Series | 150WLP-TC |
| Shank Length | 1 1/4" |
| Shank Type - Machining | Straight |
| Standards | ANSI |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 3.81 |
| Ship length (cm) | 9.84 |
| Country of Origin | US |
