| Aircraft Drill | Yes |
| Coolant Fed | Non-Coolant Through |
| Coolant Through | No |
| Cutting Direction | Right Hand |
| Drill Bit Dimension Type | Fractional Inch |
| Drill Bit Finish | Black Oxide |
| Drill Bit Grouping | Drill Bit |
| Drill Length Class | Extra Long |
| Flute Type | Spiral |
| Grade | Heavy Duty , High Performance |
| Left/right Hand | Right |
| List Number | 906 |
| Material | High Speed Steel |
| Max. Drilling Depth | 3 7/8" |
| Primary Material Application | Cast Iron, Steel |
| Primary Material Application Iso Code | K, P |
| Spiral Direction | Right Hand |
| System Of Measurement | Fractional Inch |
| Decimal Equivalent | 0.4063 |
| Depth:dia. Ratio | 4xD |
| Drill Bit Point Angle | 135° |
| Drill Bit Point Type | Split Point |
| Drill Bit Size | 13/32" |
| Drill Diameter Tolerance | 0"/-0.001" |
| Drill Point Length | 0.0841" |
| Finish - Machining | Black Oxide |
| Flute Length | 3 7/8" |
| Helix Angle | 28° |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | High Performance |
| Maximum Drilling Depth | 3 7/8" |
| Measurement System | Fractional Inch |
| Number Of Flutes | 2 |
| Overall Length | 6" |
| Shank Dia. | 25/64" |
| Shank Length | 2 1/8" |
| Shank Type - Machining | Straight |
| Standards | NOT RATED |
| Ship weight (kg) | 0.47 |
| Ship height (cm) | 3.81 |
| Ship length (cm) | 15.24 |
| Country of Origin | US |
