| Item | Terminal |
| Application | For Joining A Wide Range Of Copper Cable To Equipment Studs |
| Body Material | Copper |
| Certification | No |
| Compatible With Product Type | Copper Cable |
| Connection Orientation | Compact |
| Connector Type | Terminal |
| Contact Finish | Unplated |
| Dimension - Height Inch | 1.31" |
| Dimension - L Length Overall Mm | 67 mm |
| Dimension - Length Overall Inch | 2.63" |
| Dimension - Pad Width Inch | 1 1/4" |
| For Conductor Material | Copper |
| For Stud Size | 1/2" |
| Head Type | Hex |
| Hole Dia. | 14/25" |
| Hole Size | 14 mm , 14/25" |
| Hole Spacing | Not Applicable |
| Length | 2.63" |
| Length (straight Wireway) | 2.63" |
| Material | Copper |
| Min. Conductor Size | 3/0 AWG |
| No. Of Conductors | 1 |
| Number Of Conductors | 1 |
| Number Of Holes | 1 |
| Overall Depth | 1 1/4" |
| Physical Attribute - No. Of Screws | 1 |
| Physical Attribute - Screw Type | Hexagonal Bolt |
| Plated | N |
| Special Features | Low Contact Resistance When Gripped Between Two Contact Nuts, One Wrench Installation |
| Stud Size | 1/2" |
| Terminal Material | Copper |
| Tongue Width | 1 1/4" |
| Type | Commercial |
| Width | 1.31" |
| Wire Material | Copper |
| For Stranded Copper Wire Size - Maximum | 4/0 AWG |
| For Stranded Copper Wire Size - Minimum | 3/0 AWG |
| Head Style | Hex |
| Hole Diameter | 0.56" |
| Maximum Operating Temperature | 194°F |
| Maximum Voltage | 600V |
| Number Of Terminations | 1 |
| Overall Length | 2.63" |
| Overall Width | 1.31" |
| Standards | UL LISTED |
| Tongue Thickness | 0.31" |
| Torque | 250 lbs.-in. |
| Ship weight (kg) | 0.16 |
| Ship height (cm) | 3.33 |
| Ship length (cm) | 6.68 |
| Ship width (cm) | 3.18 |
| HS code | 8535908020 |
| Country of Origin | US |
| Model | Length | Max. Conductor Size | Min. Conductor Size | Stud Size | Width | Price | |
|---|---|---|---|---|---|---|---|
| QDA1C | 2.19" | 1 AWG | 4 AWG | 3/8" | 1" | €107.00 | |
| QDA4C | 1.88" | 4 AWG | 8 AWG | 3/8" | 0.72" | €81.77 | |
| QDA31 | 3.38" | 350 kcmil | 250 kcmil | 5/8" | 1.69" | €391.22 | |
| QDA26 | 2.5" | 2/0 AWG | 1/0 AWG | 1/2" | 1.19" | €117.29 | |
| QDA34 | 3.81" | 500 kcmil | 400 kcmil | 3/4" | 1.94" | €452.38 | |
| QDA8C | 1.88" | 8 AWG | 14 AWG | 3/8" | 0.69" | €59.99 |
