| Item | Terminal |
| Body Material | Copper |
| Compatible With Product Type | Cable |
| Connection Orientation | Compact |
| Connector Type | Terminal |
| Contact Finish | Unplated |
| For Conductor Material | Copper |
| For Stranded Copper Wire Size | 1 AWG |
| For Stranded Copper Wire Size - Minimum | 4 AWG |
| For Stud Size | 1/4" |
| Head Type | Hex |
| Hole Dia. | 7/25" |
| Hole Spacing | Not Applicable |
| Length | 1 3/4" |
| Length (straight Wireway) | 1 3/4" |
| Material | Copper |
| Max. Conductor Size | 1 AWG |
| Min. Conductor Size | 4 AWG |
| No. Of Conductors | 1 |
| Number Of Conductors | 1 |
| Number Of Holes | 1 |
| Overall Depth | 5/8" |
| Special Features | Fast Onewrench Installation, Heavy Duty, Joining A Wide Range Of Cable |
| Stud Size | 1/4" |
| Terminal Material | Copper |
| Tongue Width | 0.63" |
| Type | Commercial |
| Width | 1" |
| Wire Material | Copper |
| For Stranded Copper Wire Size - Maximum | 1 AWG |
| Head Style | Hex |
| Hole Diameter | 0.28" |
| Maximum Operating Temperature | 194°F |
| Maximum Voltage | 600V |
| Number Of Terminations | 1 |
| Overall Length | 1.75" |
| Overall Width | 1" |
| Standards | UL LISTED |
| Tongue Length | 0.75" |
| Tongue Thickness | 0.22" |
| Torque | 150 lbs.-in. |
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 4.45 |
| Ship width (cm) | 2.54 |
| HS code | 8535908020 |
| Country of Origin | US |
| Product | Model | Conductor Range | Item | Length | Max. Conductor Size | Min. Conductor Size | Overall Length | Stud Size | Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
QDA40 | - | Terminal | 4.25" | 800 kcmil | 600 kcmil | - | 1" | 2.44" | €658.55 | |
 |
Q3A344N | - | Three Conductor Terminal | 4.69" | 500 kcmil | 400 kcmil | - | 1/2" | 4.56" | €1,137.85 | |
 |
Q2A262N | - | Two Conductor Terminal | 4.19" | 2/0 AWG | 1/0 AWG | - | 1/2" | 1.94" | €349.09 | |
|
Q2A1C2 | - | Two Conductor Terminal | 2.88" | 1 AWG | 4 AWG | - | 3/8" | 1.81" | €279.63 | |
|
Q2A282N | - | Two Conductor Terminal | 4.38" | 4/0 AWG | 3/0 AWG | - | 1/2" | 1.94" | €392.16 | |
|
Q2A312N | - | Two Conductor Terminal | 4.5" | 350 kcmil | 250 kcmil | - | 1/2" | 2.13" | €768.31 | |
 |
QP10F25X03D | 8.6" | Quick Disconnect | - | - | - | 0.98" | - | 0.923" | - | RFQ
|
