| Item | UV Rated Multi Tap Connector |
| Body Finish | Plastisol |
| Body Material | Aluminium |
| Color | Black |
| Compatible With Product Type | Code Conductor |
| Connector Type | Double Sided Entry |
| Direct Burial Rated | No |
| Finish | Unplated |
| For Conductor Material | Aluminum, Copper |
| For Stranded Copper Wire Size - Minimum | 14 AWG |
| Head Type | Hex |
| Insulation | Insulated |
| Insulation Material | Plastisol |
| Length | 2.86" |
| Length (straight Wireway) | 2.86" |
| Min. Conductor Size | 14 AWG |
| Mounting Hole Size | Not Applicable |
| No. Of Ports | 4 |
| Number Of Ports | 4 |
| Rohs Compliant | Yes |
| Screw Finish | Tin Plated Steel |
| Screw Material | Aluminum |
| Screw Size | 7/16" |
| Special Features | Insulated, Oxide Inhibitor Pre-Installed Inhibits Moisture And ContamiNaNts From Entering The Contact Area, Saves Time By Eliminating The Need For Taping, Uv Rated |
| Stud Size | 0.312" |
| Tap Shape | T |
| Terminal Material | Aluminium |
| Width | 1 14/25" |
| For Stranded Copper Wire Size - Maximum | 2/0 AWG |
| Head Style | Hex |
| Hex Size | 3/16" |
| Maximum Operating Temperature | 194°F |
| Maximum Voltage | 600V |
| Minimum Operating Temperature | -40°F |
| Overall Length | 2.86" |
| Overall Width | 1 14/25" |
| Standards | UL LISTED |
| Torque | 120 lbs.-in. |
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 3.51 |
| Ship length (cm) | 7.26 |
| Ship width (cm) | 3.96 |
| HS code | 8535908040 |
| Country of Origin | US |
