| Item | Pump |
| Body Gasket Material | Carbon |
| Compatible Discharge Pipe Size | 3/4", 1", 1 1/4", 1 1/2" |
| Connection Type | FNPT |
| Electrical Connection Type | Hardwired |
| Enclosure Type | Open Dripproof |
| Face To Face Dimension | 6 3/8" |
| For Pipe Size | 3/4", 1", 1 1/4", 1 1/2" |
| For Use With | Hydronic Systems |
| For Use With Potable Systems | No |
| Frequency | 60 Hz |
| Housing Material | Bronze |
| Hp | 2/5 hp |
| Impeller Material | Glass Filled PPS |
| Max. Flow Rate @ 1 Ft. | 50 GPM |
| Max. Flow Rate @ 10 Ft. | 44 GPM |
| Max. Flow Rate @ 15 Ft. | 40 GPM |
| Max. Flow Rate @ 20 Ft. | 38 GPM |
| Max. Flow Rate @ 25 Ft. | 34 GPM |
| Max. Flow Rate @ 30 Ft. | 27 GPM |
| Max. Flow Rate @ 40 Ft. | 13 GPM |
| Max. Flow Rate @ 5 Ft. | 47 GPM |
| Max. Flow Rate @ 50 Ft. | 4 GPM |
| Max. Head | 53 ft. |
| Max. Media Temp. | 250°F |
| Max. Operating Pressure | 150 psi |
| Max. Rpm | 3250 RPM |
| Media Type | Water |
| Mounting Location | Inline |
| Mounting Position | Horizontal, Vertical |
| No. Of Flange Mounting Holes | 4 |
| No. Of Speeds | 1 |
| Overall Height | 6.38" |
| Overall Length | 9 14/25" |
| Overall Width | 4 3/4" |
| Pipe To Flange Or Union Connection Type | FNPT |
| Pump Type | Standard |
| Rotor Type | Wet |
| Self Priming | Yes |
| Series | PL Series |
| Voltage | 115V AC |
| Wetted Material | Glass Filled PPS, Plastic |
| Compatible Media Type | Water |
| Compatible Pipe Size | 3/4", 1", 1 1/4", 1 1/2" |
| Horsepower | 2/5 hp |
| Manufacturer Warranty Length | 1 yr. |
| Maximum Feet Of Head | 53 ft. |
| Maximum Flow Rate @ 1 Foot Of Head | 50 GPM |
| Maximum Flow Rate @ 10 Feet Of Head | 44 GPM |
| Maximum Flow Rate @ 15 Feet Of Head | 40 GPM |
| Maximum Flow Rate @ 20 Feet Of Head | 38 GPM |
| Maximum Flow Rate @ 25 Feet Of Head | 34 GPM |
| Maximum Flow Rate @ 30 Feet Of Head | 27 GPM |
| Maximum Flow Rate @ 40 Feet Of Head | 13 GPM |
| Maximum Flow Rate @ 5 Feet Of Head | 47 GPM |
| Maximum Flow Rate @ 50 Feet Of Head | 4 GPM |
| Maximum Media Temperature | 250°F |
| Maximum Operating Pressure | 150 psi |
| Maximum Rpm | 3250 RPM |
| Motor Enclosure Design | Open Drip Proof |
| Nameplate Voltage | 115V AC |
| Number Of Flange Mounting Holes | 4 |
| Number Of Speeds | 1 |
| Phase | Single |
| Phase And Brand | BELL & GOSSETT Single Phase |
| Priming | Self Priming |
| Pump Housing Material | Bronze |
| Series Family | PL |
| Standards | CSA CERTIFIED TO NSF/ANSI 372 |
| Ship weight (kg) | 7.34 |
| Ship height (cm) | 16.21 |
| Ship length (cm) | 24.28 |
| Ship width (cm) | 12.07 |
| Country of Origin | US |
