| Item | Compression Lug |
| Body Material | Copper |
| Cable Size | 500 kcmil |
| Cable Size Code | 500 kcmil |
| Color Code | Brown |
| Connector Type | Straight Barrel |
| Die Code | 87 |
| Hole Center To End | 0.41" |
| Length | 3 17/25" |
| Material | Copper |
| Peep Hole | Yes |
| Stud Size | 3/8" |
| Type | Standard |
| Width | 1.55" |
| Barrel Id | 0.84" |
| Barrel Od | 1.06" |
| Barrel Size | Long |
| Barrel Style | Chamfered |
| Connection Orientation | Straight |
| Contact Finish | Tin |
| Current | 620A |
| For Conductor Material | Copper |
| For Stranded Copper Wire Size - Minimum | 500 kcmil |
| For Stud Size | 3/8" |
| For Wire Type | Stranded |
| Hole Size | 0.405" |
| Inspection Hole | Yes |
| Maximum Operating Temperature | 300°F |
| Maximum Voltage | 600V AC |
| Maximum Wire Size | 500 kcmil |
| Number Of Holes | 1 |
| Overall Length | 3.68" |
| Overall Width | 1.55" |
| Rohs Compliant | Yes |
| Seam Style | Seamless |
| Special Features | Corrosion Resistant, High-Conductivity Construction |
| Standards | UL LISTED |
| Strip Length | 2 3/8" |
| Termination Style | Crimp |
| Tongue Length | 0.83" |
| Tongue Style | Standard |
| Tongue Thickness | 0.22" |
| Tongue Width | 1.55" |
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 3.38 |
| Ship length (cm) | 12.5 |
| Ship width (cm) | 7.49 |
| HS code | 8535908020 |
| Country of Origin | CN |
| Product | Model | Cable Size | Cable Size Code | Color Code | Die Code | Hole Center To End | Length | Mount | Peep Hole | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
24C312 | 8 AWG | 8 AWG | Red | 21 | 0.25" | 1.6" | 1-Hole | No | €2.82 | |
 |
24C313 | 6 AWG | 6 AWG | Blue | 24 | 0.25" | 1.65" | 1-Hole | No | €2.98 | |
 |
24C314 | 4 AWG | 4 AWG | Gray | 29 | 0.25" | 1.7" | 1-Hole | No | €3.82 | |
 |
24C315 | 2 AWG | 2 AWG | Brown | 33 | 0.25" | 1.8" | 1-Hole | No | €4.47 | |
 |
24C316 | 1 AWG | 1 AWG | Green | 37 | 0.25" | 1.78" | 1-Hole | No | €4.81 | |
 |
24C317 | 1/0 AWG | 1/0 AWG | Pink | 42 | 0.25" | 1.98" | 1-Hole | No | €5.92 | |
|
24C318 | 8 AWG | 8 AWG | Red | 21 | 0.25" | 1.57" | 1-Hole | No | €2.82 |
