| Item | Control Station |
| Approval: | UL 508/698/1203 |
| Approvals | UL |
| Box Type: | 2-Gang Tandem |
| Button Label | Start, Stop |
| Constructional Feature: | Dust Ignitionproof, Explosionproof |
| Contact Configuration: | 2NO-2NC, Universal |
| Contact Type(s) | Momentary |
| Current Rating: | 10 Ampere |
| Enclosure Material: | Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron |
| Enclosure Type | Dead End |
| Enclosure: | Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/7C/7D/9E/9F/9G |
| Family Series | Appleton Switches, EFD Series |
| Hub Size | 3/4 " |
| Hub Size: | (1) 3/4 Inch |
| Illuminated | Yes |
| Legend: | Start-Stop |
| Mounting | Panel Mount |
| Number Of Circuits: | 2 |
| Number Of Pilot Lights | 2 |
| Number Of Pilot Lights: | 2 |
| Number Of Pushbuttons | 2 |
| Number Of Pushbuttons: | 2 |
| Number Of Selector Switches | 0 |
| Operator Type: | Front Operated Button |
| Pilot Light Type: | 120 VAC 6 W 6S6 Lamp |
| Product Series | EFD |
| Total Number Of Devices | 4 |
| Type: | Dead End |
| Voltage Rating: | 600 VAC |
