| Item | Mounting Body |
| Box Type | Tandem |
| Depth | 3.06" |
| Height | 11.31" |
| Hub Size | 1/2" |
| Hub Style | Feed Thru |
| Includes | Internal Ground Screw |
| Material | Malleable Iron |
| Type | Tandem |
| Width | 3 18/25" |
| Box Height | 10 1/2" |
| Box Shape | Rectangular |
| Bracket Type | Lugs |
| Ceiling Fan Rated | Not Rated |
| Clamp Type | Clamp Not Included |
| Color | Gray |
| For Construction Type | New Construction, Remodel |
| Hazardous Location Specification | Class I, Div 1, Group C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2, Class I, Div 2, Group B, C, D |
| Hub Type | Feed Through |
| Nema Enclosure Rating | NEMA 3, NEMA 7CD, NEMA 9EFG |
| Number Of 1 In Side Knockouts | 0 |
| Number Of 1/2 In Back Knockouts | 0 |
| Number Of 1/2 In Side Knockouts | 0 |
| Number Of 3/4 In Back Knockouts | 0 |
| Number Of 3/4 In Side Knockouts | 0 |
| Number Of Gangs | 2 |
| Overall Depth | 3 1/16" |
| Overall Height | 12 1/16" |
| Overall Width | 3 3/4" |
| Standards | C22.2 NO. 14, CSA, CULUS LISTED E10449, CULUS LISTED E81751, UL 1203, UL 508, UL 698 |
| Ship weight (kg) | 6.08 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 32.51 |
| Ship width (cm) | 14.22 |
| HS code | 7325100080 |
| Country of Origin | MX |
| Product | Model | Hub Size | Hub Style | Material | Price | |
|---|---|---|---|---|---|---|
 |
EDS177 | 1/2" | Dead-End | Malleable Iron | €524.41 | |
 |
EDS177-SA | 1/2" | Dead-End | Aluminum | €524.41 | |
|
EDS277 | 3/4" | Dead-End | Malleable Iron | €523.27 | |
|
EDS277-SA | 3/4" | Dead-End | Aluminum | €524.41 | |
 |
EDS377 | 1" | Dead-End | Malleable Iron | €524.41 | |
 |
EDS377-SA | 1" | Dead-End | Aluminum | €524.41 | |
 |
EDSC177-SA | 1/2" | Feed-Thru | Aluminum | €672.26 |
