APOLLO VALVES PWR7480363 Tee Handle, 1/2 Inch Size, Powerpress
Get it by Tuesday, Jun 17
€84.66 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Tee Handle |
| Bend Angle | 90° |
| Capped | Yes |
| Color | Gray |
| Connection Type | Press x Press |
| Contour Code | DW |
| D1 | 0.84 |
| D2 | 0.84 |
| D3 | 0.84 |
| Dimensions | 2 18/25" x 4.13" x 1.26" |
| Finish | Zinc Nickel Plated |
| Flange Compression Class | PN 16 |
| Grade | Grade ST 35 |
| High Tensile Strength | Yes |
| Intrastat Code | 73079980 |
| Length Of Connection 1 | 2.05" |
| Length Of Connection 2 | 2.09" |
| Length Of Connection 3 | 2.05" |
| Material | Steel |
| Max. Media Temp. | 275°F |
| Max. Operating Pressure Liquid | 232 psi |
| Medium Temp. (continuous) | -40°F to +275°F |
| Min. Media Temp. | -40°F |
| Multi-part | No |
| Outer Pipe Dia. 1 | 21/25" |
| Outer Pipe Dia. 2 | 21/25" |
| Outer Pipe Dia. 3 | 21/25" |
| Peak Media Temp. | 302°F |
| Reducing | No |
| Seal Material | EPDM |
| Series | PowerPress Series |
| Shape | T-Piece 90º |
| Size | 1/2" |
| System Specific | Yes |
| Wall Thickness Connection 1 | 2.7 mm |
| Wall Thickness Connection 2 | 2.7 mm |
| Wall Thickness Connection 3 | 2.7 mm |
| With Buffer Stud | Yes |
| With Connection Indicator | Yes |
| With De-aerator | No |
| With Drain Valve | No |
| With Sealing Rings/gaskets | No |
| With Thermal Insulation | No |
| Working Length Connection 1 | 0.94" |
| Working Length Connection 2 | 0.98" |
| Working Length Connection 3 | 0.94" |
| Z1 | 0.95 |
| Z2 | 0.98 |
| Z3 | 0.95 |
| Ship weight (kg) | 0.26 |
| Ship height (cm) | 3.2 |
| Ship length (cm) | 6.91 |
| Ship width (cm) | 10.49 |
| Country of Origin | NL |
| Model | Price | |
|---|---|---|
| PWR7480374 | €76.18 | |
| PWR7480385 | €90.30 | |
| PWR7480396 | €153.65 | |
| PWR7480407 | €176.75 | |
| PWR7480418 | €291.35 | |
| PWR7480429 | €83.23 | |
| PWR7480431 | €101.96 |
