Get it by Wednesday, Jun 18
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
Payment
| Item | Swivel Plate Caster |
| Bearing Type | Double Ball |
| Brake Type | Pinch |
| Caster Brake Included | Yes |
| Caster Load Rating Range | 1000 lbs. to 2999 lbs. |
| Caster Material | Polyurethane |
| Caster Product Group | Swivel Caster With Brake |
| Caster Temp. Range Available | Yes |
| Caster Type | Swivel |
| Caster Wheel Material | Polyurethane |
| Caster Wheel Shape | Standard |
| Core Color | Silver |
| Core Material | Aluminum |
| Durometer | 60 Shore D |
| Extended Lead | No |
| Frame Finish | Zinc |
| Frame Material | Steel |
| Hole Pattern | B |
| Inside Bolt Hole Spacing | 3" x 3" |
| Load Rating | 1230 lbs. |
| Lock Type | No Lock Included |
| Mounting Bolt Dia. | 3/8" |
| Non-marking | Yes |
| Number Of Wheels | 1 |
| Operating Temp. Range | -40°F to +180°F |
| Outside Bolt Hole Spacing | 2 5/8" x 3 5/8" |
| Overall Height | 7 1/4" |
| Plate Caster Core Material | Aluminum |
| Plate Caster Lock | No Lock Included |
| Plate Caster Wheel Material | Polyurethane |
| Plate Size | 4" x 4 1/2" |
| Plate Thickness | 1/4" |
| Plate Type | B |
| Raceway Type | Double Ball |
| Swivel Radius | 0.0" |
| Wheel Bearing Type | Roller |
| Wheel Bearings | Roller |
| Wheel Color | Green |
| Wheel Diameter | 6" |
| Wheel Width | 2" |
| Application | Dollies, Floor Trucks, Shop Carts, Warehouse Trucks, Waste Disposal Trucks |
| Caster Brake Type | Side Pedal Brake |
| Caster Frame Material | Steel |
| Caster Sub-type | Swivel |
| Includes | Complete Caster with Brake |
| Includes Thread Guards | No |
| Mounting Height | 7 1/2" |
| Mounting Plate Bolt Hole Pattern | B |
| Mounting Plate Size | 4" x 4 1/2" |
| Mounting Plate Size & Bolt Hole Pattern | 4" x 4 1/2" ( B ) |
| Number Of Mounting Holes | 4 |
| Standards | ICWM |
| Swivel Construction | Kingpin |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Double Ball |
| Tread Shape | Standard |
| Wheel Core Material | Aluminum |
| Wheel Dia. | 6" |
| Wheel/tread Color | Green |
| Wheel/tread Hardness | 92 Shore A |
| Wheel/tread Hardness Rating | Firm |
| Wheel/tread Material | Polyurethane |
| Ship weight (kg) | 3.6 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 20.32 |
| HS code | 8302200000 |
| Product | Model | Brake Type | Caster Load Rating Range | Caster Wheel Material | Core Color | Core Material | Durometer | Frame Finish | Inside Bolt Hole Spacing | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
01RN02041S003G | Side | 0 to 299 lb. | Rubber | Black | Rubber | 75 Shore D | Zinc Plated | 15/16 x 2-1/8" | €9.62 | |
 |
02RR04151S001GN | Over-The-Wheel Strap | 0 to 299 lb. | Rubber | Black | Rubber | 80 Shore A | Nickel Plated | 1-3/4 x 3" | €27.03 | |
 |
DCIB06052S001G | Over-The-Wheel Strap | 300 to 999 lb. | Polyolefin | Black | Polyolefin | 70 Shore D | Zinc Plated | 1-3/4 x 3" | €19.52 | |
 |
02RR04028SFPQG | Over-The-Wheel Strap | 0 to 299 lb. | Rubber | Black | Rubber | 80 Shore A | Zinc Plated | 3 x 3" | €37.88 | |
 |
02TM06101SFPQGN | Over-The-Wheel Strap | 300 to 999 lb. | Phenolic | Black | Phenolic | 102 Shore E | Zinc Plated | 3 x 3" | €36.18 | |
 |
DCIB04028S001G | Over-The-Wheel Strap | 300 to 999 lb. | Polyolefin | Black | Polyolefin | 70 Shore D | Zinc Plated | 3 x 3" | €19.54 | |
|
DCIB05028S001G | Over-The-Wheel Strap | 300 to 999 lb. | Polyolefin | Black | Polyolefin | 70 Shore D | Zinc Plated | 3 x 3" | €21.05 |
