| Application | Air, Non-Potable Water |
| Color | Silver |
| Compatible Copper Tube Size | 10 mm |
| Compatible Tube Material | Copper, Nylon, Polyethylene, Polyurethane |
| Finish/coating | Nickel Plated |
| Fitting Material | Brass |
| Fitting Side A Connection Type | Push-to-Connect |
| Fitting Side A Tube Outer Diameter | 8 mm |
| Fitting Side B Connection Type | Universal |
| Fitting Side B Pipe Size | 1/8" |
| Fitting Side B Tube Outer Diameter | 10 mm |
| Fitting Thread Size | 1/8" |
| Includes Pre-applied Thread Sealant | No |
| Maximum Operating Pressure | 290 psi |
| Maximum Operating Temperature | 160°F |
| Minimum Operating Temperature | 0°F |
| Overall Length | 1 7/8" |
| Release Ring Material | Composite |
| Release Type | Collet |
| Resistance Properties | Impact Resistant, Vibration Resistant |
| Specific Fitting Shape | Wye |
| Standards | 1907/2006 REACH, 2011/65/CE ROHS, ISO 14743:2004, PED 2014/68/UE |
| System Of Measurement | Imperial/Metric |
