| Item | Fork Terminal |
| Color Code | Yellow |
| Connection Material | Copper |
| Connection Type | Lug |
| Insulation Color | Yellow |
| Insulation Material | Vinyl |
| Insulation Type | Vinyl |
| Max. Temp. | 221°F |
| Max. Voltage | 600V |
| Overall Length | 1.03" |
| Seam | Brazed |
| Stud Size | #10 |
| Terminal Type | Standard |
| Wire Size | 12 AWG to 10 AWG |
| Maximum Operating Temperature | 221°F |
| Maximum Voltage | 600V |
| Maximum Wire Size | 10 AWG |
| Minimum Wire Size | 12 AWG |
| Seam Style | Brazed |
| Standards | CSA CERTIFIED, UL LISTED |
| Tongue Width | 0.38" |
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.62 |
| Ship width (cm) | 2.54 |
| HS code | 8536698000 |
| Country of Origin | US |
| Product | Model | Color Code | Overall Length | Stud Size | Wire Range | Price | |
|---|---|---|---|---|---|---|---|
 |
7100164017 | Blue | 0.9" | #8 | 16 to 14 AWG | €662.19 |
