| Item | Ring Terminal |
| Color Code | Bare |
| Connection Material | Copper |
| Connection Orientation | Straight |
| Connection Type | Crimp |
| Contact Material | Copper |
| Contact Plating | Tin |
| Insulated | Non Insulated |
| Insulation Color | Bare |
| Insulation Type | Non Insulated |
| Max. Temp. | 347°F |
| Max. Voltage | 600V |
| Overall Length | 3/5" |
| Seam | Butted |
| Stud Size | #6 |
| Terminal Connection | Crimp |
| Terminal Connection Type | Crimp |
| Terminal Type | Standard |
| Maximum Operating Temperature | 347°F |
| Maximum Voltage | 600V |
| Maximum Wire Size | 18 AWG |
| Minimum Wire Size | 22 AWG |
| Seam Style | Butted |
| Standards | CSA CERTIFIED, UL LISTED |
| Termination | Crimp Termination Only |
| Tongue Width | 1/4" |
| Ship weight (kg) | 0.54 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 1.52 |
| Ship width (cm) | 2.54 |
| HS code | 8536904000 |
| Country of Origin | US |
| Product | Model | Overall Length | Stud Size | Wire Range | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|
 |
7010351316 | 0.74" | #8 | 22 to 18 AWG | 100 | €143.68 | |
|
7010398241 | 0.74" | #8 | 16 to 14 AWG | 100 | €140.92 | |
|
7010320793 | 0.73" | #8 | 12 to 10 AWG | 50 | €66.88 | |
 |
7100164077 | 0.96" | 1/4" | 12 to 10 AWG | 500 | €251.55 | |
 |
7100163917 | 0.74" | #8 | 22 to 18 AWG | 1 | €257.34 | |
 |
7100163918 | 0.74" | #10 | 22 to 18 AWG | 1 | €276.34 | |
 |
7100163915 | 0.6" | #4 | 22 to 18 AWG | 1 | €260.94 |
