| Item | Ring Terminal |
| Color Code | Bare |
| Connection Finish | Nickel Plated |
| Connection Material | Steel |
| Connection Orientation | Straight |
| Connection Type | Crimp |
| Contact Material | Steel |
| Contact Plating | Nickel |
| Insulated | Non Insulated |
| Insulation Color | Bare |
| Insulation Type | Non Insulated |
| Max. Temp. | 900°F |
| Max. Voltage | 600V |
| Overall Length | 0.99" |
| Seam | Butted |
| Stud Size | 1/4" |
| Terminal Connection | Crimp |
| Terminal Connection Type | Crimp |
| Terminal Type | Standard |
| Maximum Operating Temperature | 900°F |
| Maximum Voltage | 600V |
| Maximum Wire Size | 10 AWG |
| Minimum Wire Size | 12 AWG |
| Seam Style | Butted |
| Standards | CSA CERTIFIED, UL LISTED |
| Termination | Crimp Termination Only |
| Tongue Width | 0.59" |
| Ship weight (kg) | 1.08 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.51 |
| Ship width (cm) | 2.54 |
| HS code | 8536904000 |
| Country of Origin | US |
| Product | Model | Insulation Type | Overall Length | Stud Size | Wire Range | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|
 |
7000132266 | Noninsulated | 0.73" | #10 | 12 to 10 AWG | 500 | €224.96 | |
 |
7000132254 | Noninsulated | 0.7" | #10 | 16 to 14 AWG | 1 | €286.01 | |
 |
7000132273 | Noninsulated | 0.95" | 1/4" | 8 AWG | 200 | €247.78 | |
|
7100164158 | Noninsulated | 1.22" | 3/8" | 6 AWG | 200 | €396.45 | |
|
7100164165 | Noninsulated | 1.34" | 3/8" | 4 AWG | 200 | €572.43 | |
 |
7000133346 | Bare | 0.73" | #10 | 12 to 10 AWG | 50 | €91.66 | |
|
7000133345 | Bare | 0.7" | #10 | 16 to 14 AWG | 100 | €120.62 |
