| Item | Fork Terminal |
| Color Code | Yellow |
| Connection Material | Copper |
| Connection Orientation | Straight |
| Connection Type | Lug |
| Insulated | Insulated Barrel |
| Insulation Color | Yellow |
| Insulation Material | Heat Shrink Polyolefin |
| Insulation Type | Heat Shrink |
| Max. Temp. | 221°F |
| Max. Voltage | 600V |
| Overall Length | 1" |
| Seam | Brazed |
| Stud Size | #8 |
| Terminal Type | Locking |
| Wire Size | 12 AWG to 10 AWG |
| Maximum Operating Temperature | 221°F |
| Maximum Voltage | 600V |
| Maximum Wire Size | 10 AWG |
| Minimum Wire Size | 12 AWG |
| Seam Style | Brazed |
| Standards | CSA CERTIFIED, UL LISTED |
| Tongue Width | 0.32" |
| Ship weight (kg) | 0.5 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| HS code | 8536698000 |
| Country of Origin | US |
| Product | Model | Color Code | Overall Length | Stud Size | Wire Range | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|
 |
7100164269 | Yellow | 1.2" | 1/4" | 12 to 10 AWG | 1 | €427.49 | |
 |
7100164290 | Blue | 1" | #8 | 16 to 14 AWG | 250 | €245.94 | |
 |
7100164268 | Yellow | 1" | #10 | 12 to 10 AWG | 250 | €407.06 | |
 |
7100164291 | Red | 1" | #8 | 22 to 18 AWG | 250 | €245.94 | |
 |
7100164284 | Red | 1" | #10 | 22 to 18 AWG | 250 | €245.94 | |
 |
7100164275 | Blue | 1" | #10 | 16 to 14 AWG | 250 | €245.94 | |
 |
7100017420 | Yellow | 1" | #8 | 12 to 10 AWG | 25 | €83.92 |
