| Item | Cold Shrink Tubing |
| Adhesive Lined | No |
| Application | Insulation, Mechanical Protection, Repair |
| Color | Black |
| Conductor Material | Aluminum, Copper |
| Flame Retardant | No |
| I.d. After Shrinking | 0.55" |
| I.d. Before Shrinking | 1.18" |
| Inner Diameter After Shrink | 0.547" |
| Inner Diameter Before Shrink | 1.185" |
| Length | 11" |
| Length (straight Wireway) | 11" |
| Material | EPDM Rubber |
| Max. Connector Length | 7" |
| Max. Voltage | 1000V |
| Maximum Conductor Size | 246 kcmil |
| Model | Cold-Shrink |
| No. Of Conductors | 1 |
| Package Style | Individual Pieces |
| Shrink Ratio | Not Rated |
| Shrink Temp. | Not Applicable |
| Shrink Tube Material Type | Flexible |
| Shrink Tubing Adhesive Lined | No |
| Shrink Tubing I.d. Before Shrinking | 1.18" |
| Shrink Tubing Length | 11" |
| Shrink Tubing Wall Type | Medium Wall |
| Splice Type | Cold Shrink |
| Temp. Range | -40°F to +194°F |
| Voltage | 1 kV |
| Voltage Application | Low Voltage |
| Wall Thickness After Shrinking | Not Applicable |
| Wall Type | Medium Wall |
| Dielectric Strength | 1000V |
| Features | Requires No Tools or Heat, Moisture Tight Seal, Suitable for Direct Buried Applications |
| Max. Temp. Rating | 194°F |
| Min. Temp. Rating | -40°F |
| Shrink Tubing Properties | UV Light Resistant |
| Standards | ANSI C119.1 |
| Tubing Wall Type | Medium Wall |
| Use With Wire Size | 2/0 AWG to 250 mcm |
| Ship weight (kg) | 1.17 |
| Ship height (cm) | 14.22 |
| Ship length (cm) | 35.81 |
| Ship width (cm) | 21.08 |
| HS code | 3926909980 |
| Country of Origin | US |
| Product | Model | Cable Range | I.d. After Shrinking | I.d. Before Shrinking | Item | Length | Material | Max. Voltage | Temp. Range | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
7100164895 | - | 0.95" | 1.94" | Cold Shrink Tubing | 6" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 50 | €3,871.75 | |
|
7000005997 | - | 0.95" | 1.94" | Cold Shrink Tubing | 6" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €579.41 | |
 |
7000145516 | - | 1.27" | 2.67" | Cold Shrink Tubing | 9" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €940.09 | |
|
7000058072 | - | 1.27" | 2.67" | Cold Shrink Tubing | 6" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €530.35 | |
 |
7100010774 | - | 0.67" | 1.38" | Cold Shrink Tubing | 16" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €1,094.23 | |
 |
7000132443 | - | 0.67" | 1.38" | Cold Shrink Tubing | 6" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €416.49 | |
 |
7000005944 | - | 0.95" | 1.94" | Cold Shrink Tubing | 18" | EPDM Rubber | 1000 | -40 Degrees to 194 Degrees F | 10 | €1,732.72 |
