| Item | Shielding Foil Tape |
| Adhesive Properties | Conductive |
| Color | Copper |
| Core Dia. | 3" |
| Duct Tape Adhesive | Acrylic |
| Liner Included | Yes |
| Material | Copper Foil |
| Max. Performance Temp. | Not Rated |
| Min. Performance Temp. | Not Rated |
| Number Of Adhesive Sides | 1 |
| Product Form | Continuous Roll |
| Shape | Continuous Roll |
| Tape Backing Construction | Foil |
| Tape Type | Foil |
| Adhesion To Steel | 35 oz./in. |
| Breaking Strength | 25 lbs./in. |
| Imperial Tape Length | 54 ft. |
| Imperial Tape Width | 3/8" |
| Maximum Tape Performance Temperature | Not Rated |
| Metric Tape Length | 16.5m |
| Metric Tape Width | 9.5 mm |
| Minimum Tape Performance Temperature | Not Rated |
| Series | 1245 Series |
| Shielding Effectiveness | Excellent (Over 85dB) |
| Specifications Met | EU, RoHS, UL Listed |
| Standards | ROHS 2011/65/EU, UL LISTED |
| Tape Adhesive Format | Single-Sided |
| Tape Adhesive Material | Acrylic |
| Tape Backing Material | Copper |
| Tape Color | Copper |
| Tape Properties | EMI Shielding, Flame Retardant |
| Tape Resistance Properties | Contact-Resistant, Oxidation-Resistant |
| Tape Sub-type | General Purpose Foil |
| Tape Tensile Strength | 25 lbs./in. |
| Tape Thickness | 4 mil. |
| Voltage Rating | 600V |
| Ship weight (kg) | 2.39 |
| Country of Origin | TW |
| Model | Pkg. Qty. | Price | |
|---|---|---|---|
| 7010395786 | 12 | €1,246.43 | RFQ
|
| 7000132704 | 36 | €1,245.90 | RFQ
|
| 7000140703 | 18 | €1,210.79 | RFQ
|
| 7000132179 | 9 | €1,281.97 | RFQ
|
