| 20 | $47.83 |
| 60 | $39.86 |
| Bore (b1) | 0.6250 in |
| Bore Tolerance | +0.0020 in / +0.0005 in |
| Clearance Diameter (c) Max | 1.500 in |
| Finish Specification | Hot Process Black Oxide, Impregnated with Naphthenic Oil, Centrifugally Dried |
| Forged Clamp Screw | #10-32 |
| Hex Wrench Size | 5/32 in |
| Length (l) | 15/16 in |
| Material Specification | 1215 Carbon Steel Bar |
| Moment Of Inertia | 0.0640 lb-in |
| Number Of Screws | 4 ea |
| Outer Diameter (od) | 1 5/16 in |
| Recommended Gap | 0.063 in |
| Recommended Hex Key | Inch Hex Keys |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Black Oxide |
| Screw Location (r) | 0.484 in |
| Screw Material | Alloy Steel |
| Seating Torque | 76 lb-in |
| Small Bore (b2) | 0.5000 in |
| Temperature | -40°F to 350°F (-40°C to 176°C) |
| Torque Wrench | TW:BT-4C-3/8-76 |
| Width (w) | 15/16 in |
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 3.34 |
| Ship length (cm) | 2.38 |
| Ship width (cm) | 2.38 |
| Country of Origin | US |
